LOCKING SPRINGS
TYPE OF BLOCKING
There are several variants of the blocking, which can vary depending on the application. A blocking spring with flexible blocking is typically used in an office chair or seat, as this rebounds despite the blocking. Locking springs with rigid locking are used, for example, on tables / desks that are adjustable in height. No rebound is desired there, which means that rigid blocking is possible.
| Dimension (d/D) | B (Hub) | A (total length extended) | F1- Power | |
|---|---|---|---|---|
| flexible blocking | 10/22 | 20-150 mm | 140-420 mm | 200-700N |
| rigid blocking in pressure direction | 10/22 | 60-120 mm | 280-400 mm | 200-700N |
| rigid blocking in the direction of pull | 10/22 | 60-120 mm | 240-360 mm | 200-700N |
| flexible blocking | 10/27 | 30-300 mm | 160-700 mm | 200-1500N |
| rigid blocking in pressure direction | 10/27 | 60-120 mm | 280-460 mm | 200-800N |
| rigid blocking in the direction of pull | 10/27 | 60-120 mm | 240-520 mm | 200-800N |
